Screenprinted effect?

Discussion in 'Logo Design & Brand Identity Forum:' started by Music To The Eyes, Mar 2, 2010.

  1. Music To The Eyes

    Music To The Eyes Senior Member

    Does anyone know how to achieve a screenprinted effect on type? I'm going for a rustic feel, so it looks like the ink is running out in patches. I can't find anything useful by googling - was hoping someone might have some inspiration? :)
  2. Anon.

    Anon. Senior Member

  3. mrp2049

    mrp2049 Senior Member

    I can explain it perfectly later, I'm on my phone right now and it is hard to type long explanations!
  4. Music To The Eyes

    Music To The Eyes Senior Member

    Thanks, that would be great!

    Thanks for the link Anon - it's not what I'm after though. I'm looking for more of a texture sort of effect. :)
  5. Anon.

    Anon. Senior Member

    Ah ok, no worries.

    Mike (Mrp) is pretty handy with textures so I’m sure he’ll sort you out. :up:
  6. Music To The Eyes

    Music To The Eyes Senior Member

    Off the phone yet? :p
  7. glenwheeler

    glenwheeler Senior Member

    You could use a pattern over the top of your image maybe Helen. is decent for them.
  8. mrp2049

    mrp2049 Senior Member

    Right, I've just got home, seriously long day out!

    So here we go with an explanation, 3 routes, I'll go from simple to hard with varying effects.

    1. The eraser. Find yourself some brushes misprinted type 4.0_art, design and type (1998-2009) Eduardo Recife has a few good ones, or just google texture brushes, and set the opacity of the eraser to about 30% and get erasing. This is a bit hit or miss as you might hit the mark, or you might spend ages trying to erase parts and still not find the mark.


    edges on this were done this way. its good providing you chip away at it rather than trying to just erase a massive section at once.

    2. The overlay. This is again another route that depends on your background. First things first, get some texture images, google it, macro on your camera and take some photos of the floor, walls, etc or scan things. Add a new layer, place the texture in there and resize it to suit, above the text layer, and change the layer settings to overlay, mess with the opacity, i usually go with 30%ish, repeat it 3 or 4 times till you get a setting you like.

    You will find a few different problems with this, first of it depends on what colour you want the text, second, it depends on the background colour. I you are having problems with the text colour, desaturate the texture layer (apple+shift+u) and it will eventually balance out. If the texture is effecting the background, then magic wand/select layer/mask the text (personal preference, its up to you) so the texture only covers the text.


    background on here is done this way.

    3. Using textures to erase. Right open any of your textures, unlock the layer, desaturate the image, play with your levels or contrast brightness or both, bit hard to explain the exact specifics as I don't know what textures you have, but your aim is to get it as black and white as possible with alot less grey.


    take this as an example, it needs the levels ramped up to make the grey more white. Now once you have a more black and white texture, use the colour selection tool, once again play with the fuzziness to get more or less detail depending on what you want, select the black or the white, either is good, but I favour selecting the black, and then selection inversing and deleting everything else.

    All you should be left with is the black detail, now take the black detail into your text file and use the magic wand/select layer to highlight the black detail and then select the text layer, make sure it is also unlocked and then deleted the selected area from the text.


    texture detail on the text was done this way.

    Does that make sense? Whilst I use textures the are generally of the floor, you can get this sort of thing...


    by googling screen print texture.

    If it doesn't I guess I could write my first tutorial!
  9. matt

    matt Member

    or... buy a small screen printing set, and do it for real? Why does everyone rely so heavily on Photoshop to approximate something so easy to achieve for real.
  10. mrp2049

    mrp2049 Senior Member

    If we are talking screen print effect on text, I'd say this route is probably the safest. I agree doing it for real is never a bad thing, but personally I have had just as much success doing it this way rather than for real. Screen printing is a real art form, one that I really enjoy the technical aspect of, and I would say to get a worn/roughly printed effect is very difficult to achieve with zero experience in the discipline.

    Don't get me wrong I love the imperfection of a real print, but as a test, this is a much safer option.
  11. matt

    matt Member

    If you want a worn/roughly (badly) printed effect, then doing so with no experience is surely the best way.

    Agreed, there's no cmd+z option in the real world, and the effect can't be subtly added reduced, but that's the beauty and appeal of doing something for real — the unexpected results.
  12. Jimlad

    Jimlad Well-Known Member

    Some nice tips there, mrp2049.
  13. Music To The Eyes

    Music To The Eyes Senior Member

    Thanks Mike, you're a life saver!

    I went with the brushes option in the end - I actually already had those misprinted type brushes installed - can't believe it didn't occur to me to use them! :confused:

    matt - I would have loved to have done it for real, but this was for some visuals for a client pitch which is this afternoon, so didn't have time to go out and find a screenprinting machine sadly!
  14. mrp2049

    mrp2049 Senior Member

    No problem, once the blog is up and running ill gladly reword it as a tutorial with examples
  15. Greg

    Greg Active Member

    Sounds great to me Mike (nod)
  16. mrp2049

    mrp2049 Senior Member

    whenever you are ready.
